20m 95mm2 000 Gauge Welding Cable Solar Car Battery
$849.00
Product Introduction
20m Australian-made welding cable with 95mm2 (000 AWG) oxygen-free copper conductors, double insulated NBR/NBR to V90HT, soft and flexible for welding applications, complies to AS1995:2003.
Specifications
| Length | 20m |
| Cross Section | 95mm2 |
| Gauge | 000 AWG |
| Max Current (30% Duty Cycle) | 794 Amp |
| Insulation | Double NBR/NBR (90¡ãC rated) |
Premium Australian-Made 20m Powerflex Welding Cable – 95mm2 for Heavy-Duty Welding Applications
| Description | Double-insulated NBR/NBR welding cable with 100% oxygen-free copper conductors, designed for superior flexibility and performance in professional welding environments. |
|---|---|
| Core Selling Points | Australian made | 90¡ãC heat resistance | 794A max current (30% duty cycle) | Ultra-soft flexibility | High-purity copper |
| Product Parameters | 20m length | 95mm2 cross-section | 000 AWG gauge | Orange outer shell | AS1995:2003 compliance |
| Applications | Industrial welding machinery | Construction sites | Manufacturing facilities | Mining operations | Heavy equipment repair |
| Core Performance | Extra-fine copper strands ensure minimal voltage drop; double insulation provides enhanced durability and safety in harsh conditions. |
| Quality Assurance | Manufactured to Australian standards with rigorous testing for conductivity, flexibility, and temperature resistance. |
| Differentiation | Superior softness compared to standard cables; oxygen-free copper construction for longer service life; UNIMIG equivalent part #WC95MM. |
Why Choose Our Powerflex Welding Cable?
Engineered for professionals who demand reliability, this Australian-made cable combines exceptional flexibility with industrial-grade performance. The double NBR insulation withstands extreme temperatures up to 90¡ãC, while the high-purity copper conductors ensure maximum current transfer with minimal energy loss. Whether you’re working on construction sites or heavy manufacturing, this cable delivers consistent performance under the toughest conditions.
Frequently Asked Questions
- What is the maximum current rating? 794A at 30% duty cycle (see photos for alternate duty cycle specifications).
- Is the cable supplied as a single length? Yes, the full 20m is provided in one continuous piece.
- Does it meet Australian safety standards? Fully compliant with AS1995:2003 for welding applications.
Request a Quote Today
For bulk pricing or technical inquiries about our Powerflex welding cable, contact our sales team. Experience the difference of Australian quality in your welding operations.
Packaging & Transportation
