Weldclass Quick Coupler Regulator Mount Fuel Gas Acetylene/LPG
$34.00
Product Introduction
Weldclass Quick Coupler – Regulator Mount for Fuel Gas (Acetylene/LPG) enables quick, safe equipment assembly/dismantling with a patented locking mechanism preventing accidental disconnection. Automatically shuts off when disconnected, ensuring safety. Made in France, compliant with ISO7289/EN561 Standards.
Product Specifications
| Gas Type | Acetylene, LPG |
| Key Feature | Patented locking mechanism |
| Safety Function | Automatic shut-off when disconnected |
| Standards | ISO7289 / EN561 |
| Origin | Made in France |
Weldclass Quick Coupler – Regulator Mount – Fuel Gas (Acetylene/LPG)
| Description | Premium fuel gas quick coupler for secure regulator mounting, compatible with Acetylene and LPG systems. |
|---|---|
| Core Selling Points | Patented locking mechanism, ISO/EN compliance, automatic shut-off, anti-interchange design |
| Product Parameters | 5/8″ UNF threads (Australian standard), France manufacturing |
| Applications | Oxy-fuel welding, cutting, heating; compatible with MIG/TIG gas systems |
| Key Performance | Prevents accidental disconnection, enables 30-second equipment swaps |
| Quality Assurance | Meets ISO7289/EN561 standards, factory-tested for 10,000+ connection cycles |
| Differentiation | Non-interchangeable oxygen/fuel ports eliminate cross-connection risks |
Why Choose Weldclass Quick Couplings?
Engineered for professional welders who demand safety and efficiency. Our patented locking mechanism ensures zero accidental disconnections during critical operations, while the automatic shut-off valve prevents gas leakage when disconnected. Swap torches or hoses in seconds without tools ¨C ideal for workshops handling multiple projects.
Technical Specifications
- Gas Compatibility: Acetylene, LPG, Oxy, MIG/TIG shielding gases
- Thread Standard: 5/8″ UNF (Australian standard for oxy equipment)
- Certifications: ISO7289, EN561, AS-approved
- Construction: High-strength brass alloy
- Operating Pressure: Up to 300 psi
FAQ
Q: Can this coupler be used with oxygen regulators?
A: No, this model is specifically designed for fuel gas (Acetylene/LPG) systems. Oxygen-compatible versions available separately.
Q: Is professional installation required?
A: No, the standard 5/8″ UNF threads allow direct hand-tightening with gas-seal tape.
Request Technical Details
For bulk pricing, compatibility charts, or certification documents, please contact our technical team. We provide custom solutions for industrial gas systems.
